2WD 15,000 Series Mobile Dyno Trailer

Best Built Dyno Trailers In the Industry - 2WD 15,000 Series Mobile Chassis Dynamometer

The 15,000 series is the world’s best built chassis dynamometer in its class at any price. The 15,000 series is capable of supporting speeds up to 240 MPH and 2400+ HP. The maximum axle weight is 14,000 lbs and the track width range is 28”-86”. The 15,000 series chassis dyno’s are also upgradeable for the eddy brake for steady state testing, which can support an additional 950 HP. The 15,000 comes standard with our X Factor Knurling option which provides the highest traction over all other competitors. The optional eddy brake assembly sits directly on the shaft between the two rolls - no need to couple with a belt or universal joint all power is directly transferred from the wheels to the load cell.

Performance Specs

• Max speed: 240+ MPH
• Max power: 2,400+ HP
• Max axle weight: 14,000 lbs
• Track width range: 30"–102"
• Eddy brake upgrade (DC-PAU-750): 850+ HP additional load capacity
• World's largest eddy brake: 3,000+ ft lbs of torque support

SPECIFICATIONS:
 Max Axle Weight:   14,000 Ibs.

Max Horsepower:  2900 HP

Max Speed:  240 MPH

Max Steady State Torque*:  2,300 ft. Ibs. per retarder

Max Dynamic Torque:    15,000 ft. Ibs. per axle

Electrical Requirements:   220/240 VAC @ 30AMPs

Air Requirements:  120 PSI (For air brakes)

Specification Trailer:
•   PORTABLE DOT DYNO TRAILER
•   20’ FLAT DECK SPACE 3” TAPPER ON BOTH ENDS
•   14,000 GVWR (TWO 7000 LB. CUSTOM TORFLEX DEXTER AXLES) WITH ELECTRIC BREAKS ON BOTH AXLES
•   ONE 2 5/16 ADJUSTABLE COUPLER
•   DOT APPROVED SAFETY CHAINS
•   DOT APPROVED BREAKAWAY SYSTEM WITH BATTERY
•   DOT APPROVED SAFETY REFLECTIVE TAPE
•   DOT APPROVED LED LIGHTS
•   6 TIE DOWN RINGS (2 IN FRONT / 4 IN REAR)
•   PAINT - CHOICE
•   INSTALLATION OF DYNAMOMETER INTO TRAILER
*NOTE: TAX TITLE TRANSFER AND TAGS ARE NOT INCLUDED
