7500HT Plus "KONG" Dynamometer

7500HT Plus “KONG” — The Most Powerful Hub Dyno on the Planet

Meet KONG. The Dynocom 7500HT Plus is not just a dynamometer — it’s a statement. Built for the shops that push limits others won’t even approach, KONG delivers a staggering 26,800 lbs of total steady state torque and over 8,200 HP capacity. If you’re testing the world’s most powerful builds, you need the world’s most capable dyno.

Performance Specifications

• Max Steady State Torque: 26,800 lbs (total)
• Max HP (based on RPM): 8,200+ HP
• Max Speed (based on tire diameter): 210 MPH
• Number of Eddy Brakes: 3 per side (6 total)
• Electrical Requirements: 240VAC @ 50 Amps per unit (100 Amps total)

Enhanced Heavy-Duty Features

• Larger Diameter Outrigger Arms — 3″ Solid
• HD 9310 Steel Driveshafts
• 6″ HD Increased Height Base Support
• Larger HD Output Shaft U-Joint
• HT GearDrive/Transmission
• Exclusive “KONG” Graphics Color Scheme

Every component of KONG is engineered for extreme duty — from the 9310 steel driveshafts to the HT GearDrive transmission. This is the dyno for shops that refuse to compromise.
